Handheld thermometer DTM3000 for thermocouples
DTM3000 for thermocouples
The DTM3000 for thermocouples electronic digital thermometer features high accuracy, low power consumption, light weight and easy handling.It is designed for accurate measurements in a wide temperature range. The resolution of the instrument is 0.1°C.
The instrument is switched on by pressing the "on/off" key. Two additional keys allow a comfortable measuring operation. The "max/min" key is used to store the minimum and maximum measured values. When this key is pressed for approx. 3s, the previous values are deleted. The "hold" - key enables the storage of the last measured value.
With the built-in serial interface the measured values can be transferred and stored on the PC. Furthermore, offset, measuring cycle, resolution and switch-off time can be configured.
The associated USB interface cable including evaluation software can be purchased as an accessory.
Scope of delivery:
DTM3000 for thermocouples
9V block battery
An overview of some of our offered probes can be found here
Please note that not all offered probes have a suitable connector.
Individual temperature probes are possible on request at any time.
| Input: | Thermocouple types K, T, J, S, B, N |
et by manufacturer |
| Measuring range: | Type K -200...1370°C | DTM3000-K |
| Type T -200...400°C | DTM3000-T | |
| Type J -200...1200°C | DTM3000-J | |
| Type S 0...1760°C | DTM3000-S | |
| Type B 300...1820°C | DTM3000-B | |
| Type N -270...1300°C | DTM3000-N | |
| Resolution: | 0.1°C/1°C | configurable via software |
| Measurement accuracy: | < +/- 0,5 K | |
| Measurement rate: | maximum 4/s | configurable via software |
| Functions: | min/max, hold | |
| Battery: | 9V block 6F22 | |
| Battery life: | approx. 500h at 1/s | |
| Interface: | RS 232 or USB | The adapter must be purchased separately |
| Reference junction compensation: | internal | et by manufacturer |
| Connection: | Miniature thermocouple socket | DTM3000-K |
| Operating temperature range: | 0...60°C | DTM3000-T |
Documents
| Document | Format | Language(s) |
|---|---|---|
| Datasheet – DTM3000 for Thermocouples Technical Specification |
  |
|
| Operating Instructions – DTM3000 for Thermocouples Installation and operating manual |
|
Software
| Program / Package | Format | Language(s) |
|---|---|---|
| Service Program – DualDevice for Windows-PCs Parameterization Software |
ZIP | |
