The price stated applies to the following geometric dimensions and to accuracy class 2:
Diameter:
3mm
Length:
200mm
Technical data
measuring range
-50...+1100°C (depending on thermocouple)
mating
NiCr-Ni (K), Fe-CuNi (J), Cu-CuNi (T) nach DIN EN 60584, Fe-Konst. (L) nach DIN 43710, Messstelle vom Schutzrohr nicht isoliert NiCr-Ni (K), Fe-CuNi (J), Cu-CuNi (T) according to DIN EN 60584, Fe-const. (L) acc. to DIN 43710, measuring point not insulated from protective tube
accuracy class
2
sheath ød
1 / 1,5 / 2 / 3 / 4,5 / 6mm
sheath material
for type K 2.4816 (Inconel), 24841, for type J, L, T: 1.4541
Nominal length NL
200mm (default)
handle
double shell made of PA black (max. 130°C), with anti-kink spring
connecting lead
1.5m special PVC-insulated compensating cable (Tmax. 105°C) with free ends
insulation resistance
≥ 100 MΩ bei 20°C (100V DC)
Options
Miniature thermo plug or plug according to specifications
Ordering information for manual thermocouple probes:
Other diameters and lengths are available on request.
The specified operating temperature range refers to the sensitive part in the measuring tip.
The material-dependent characteristic values (PA max. 130°C, silicone max. 200°C, PTFE max. 250°C) apply to the max. permissible temperature at the handle and the compensating cable.
Standard compensating cable PVC-insulated, length 1.5m with free ends; other lengths and cable types as well as other thermowell lengths and diameters on request; connection ends or plug according to specification
