The price stated applies to the following geometric dimensions and to accuracy class 2:
Diameter:
3mm
Length:
100mm
Technical data
measuring range
-50...+260°C (depending on thermocouple)
mating
NiCr-Ni (K), Fe-CuNi (J), Cu-CuNi (T) according to DIN EN 60584, Fe-const. (L) acc. to DIN 43710, measuring point not insulated from protective tube
accuracy class
1
Protection tube ød
2…6mm, mit Einstechspitze zentrisch (Standard) oder schräg angeschliffen
Protection tube material
1.4401 or 1.4301
Nominal length NL
100mm (default)
handle
Teflon PTFE (max. 180°C), white
connecting lead
1.5m silicone/FEP insulated thermocouple cable with free ends
Options
Miniature thermo plug or plug according to specifications
Ordering information for manual thermocouple probes:
Other diameters and lengths are available on request.
The specified operating temperature range refers to the sensitive part in the measuring tip.
The material-dependent characteristic values (PA max. 130°C, silicone max. 200°C, PTFE max. 250°C) apply to the max. permissible temperature at the handle and the compensating cable.
Standard compensating cable PVC-insulated, length 1.5m with free ends; other lengths and cable types as well as other thermowell lengths and diameters on request; connection ends or plug according to specification
